Key Technology: Sky Spring Harvest AWG (GENAQ, Spain) Overview

Key Technology: (GENAQ, Spain)

Sky Spring Harvest AWG Machines

  Overview: Advanced refrigeration-based system extracts pure water from atmospheric humidity, integrated with Japanese bottling machinery for premium bottled water production.

   Cumulus C5000 Specifications



Version: 3.1 or 3.3

Nominal Generation Capacity: 5,091 L/day or 5,192 L/day or 5,912 L/day (at 30°C and 80% RH ±10%; variation across sources)

Dimensions (Height x Width x Depth): 2175 x 2270 x 3670 mm (generator only)

Weight: 2,200 kg (generator only)

Dimensions with Containerized Setup (Height x Width x Depth): 2600 x 2240 x 6060 mm (20-ft container)

Weight with Containerized Setup: 10,000 kg

Power Supply: 400V three-phase 50 Hz

Nominal Power: 38.6 kW or 50 kW

Plug/Socket: Direct connection (3x25mm)

Nominal Energy Consumption: 0.26 kWh/L (up to 0.95 kWh/L in low RH)

Refrigerant Circuit: Double cooling circuit for reliability and redundancy; copper tubes with aluminium fins, epoxy lacquered.

Portability: Modular sections; 20-ft containerized for rapid deployment (truck, ship, air); includes optional integrated power unit.

Storage: External tank up to 2,000 L.

Ideal Use: Large disaster response, full-scale hubs (e.g., QLD/WA); export-scale production; military/civilian camps.
